esponse spectral range |
4.4μm, 5.0μm, 3.8μm |
Response time |
15s |
Viewing angle range |
≤110 ° |
Detection distance |
Class I |
Ambient temperature |
-10 ~ 55 ℃ |
Response spectral range |
4.4μm, 5.0μm, 3.8μm |
Response time |
15s |
Viewing angle range |
≤110 ° |
Detection distance |
Class I |
Ambient temperature |
-10 ~ 55 ℃ |
Environmental humidity |
≤95% RH |
Pressure range |
86 ~ 106Kpa |
Working voltage |
DC24V |
Working current |
current≤25mA, alarm current≤35mA |
Executive standard |
GB15631-2008 |
Explosion-proof grade |
EXdⅡCT6 |
Protection grade |
IP66 |
Signal output |
Switching relay contact output, RS-485 (built-in DIP switch, can set the address of the detector) |
Mechanical structure |
|
Installation method |
wall or ceiling |
Cable outlet thread |
20mmX1.5mm free conversion G1 / 2 optional |
Dimensions |
(190X160X110) mm |
Shell material: |
die-cast aluminum |
Weight |
1Kg |
Advantages |
dustproof, explosion-proof, corrosion-proof |
